Universal Light Bar Kit, 2', 2000lm, 120-277V, 2 Bars, 3500K|5000K CCT

By Industrial Lighting Products

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Universal Light Bar Kit, 2', 2000lm, 120-277V, 2 Bars, 3500K|5000K CCT

$40.00
  • SKU: ILP-ULB2-20L-U-L2
  • MPN: ULB2-20L-U-L2

Quick Overview

2' LED retrofit light bar kit for upgrading fluorescent fixtures, delivering selectable 2300/2900/3600 lumens, 14/18/22W, 120-277V input, 0-10V dimming, and damp-location suitability.

ETL Listed
DLC Standard
Title 24 Compliant
DAMP RATED
WARRANTY 5 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The ILP Universal Light Bar Kit is a versatile LED retrofit solution designed to modernize existing fluorescent strip and troffer fixtures with faster installation and improved efficiency. As part of ILP’s retrofit lineup, it combines magnetic alignment, quick-connect wiring, and field-selectable output to simplify upgrades across commercial spaces.

Key Features and Benefits

  • Field-selectable lumen package lets you tune light levels for changing space needs.
  • Magnetic backing and included self-tapping Tek screws speed installation and improve alignment.
  • 0-10V dimming capability supports energy-saving control strategies and smoother light adjustment.
  • Long-life LED system delivers over 100,000-hour L70 performance for reduced maintenance.
  • ETL Listed, DLC Standard qualified, FCC compliant, and Title 24 compliant with sensor option for code-focused projects.
  • Backed by a 5-year standard warranty with optional 10-year coverage.

Specifications

  • Lumen Output: 2300|2900|3600
  • Wattage: 14W|18W|22W
  • Voltage: 120-277V
  • Color Temperature: 3500K|5000K
  • CRI: 80
  • Power Factor: 0.90
  • THD: 20
  • Efficacy (lm/W): 164|161|163
  • Rated Life (70 Hours): 100000
  • Max Ambient Temperature: 122°F (50°C)
  • Housing Material: Plastic
  • Lens Material: Frosted Polycarbonate
  • Damp Rated: true

Common Uses

Ideal for education, healthcare, office, grocery, retail, storage, residential, and stairwell environments where existing T8, T12, or T5/T5HO fluorescent fixtures are being converted to efficient LED operation.

RESOURCES AND DOWNLOADS

Universal Light Bar Kit Spec Sheet
