LED T1-3/4 Midget Flange Base, White, 24-28VAC/DC

By Eiko Global

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

LED T1-3/4 Midget Flange Base, White, 24-28VAC/DC

$3.45
  • SKU: E-LED-24-MG-W
  • MPN: LED-24-MG-W

Quick Overview

Compact LED T1-3/4 midget flange base bulb with selectable 24-28VAC/DC voltage, emitting white light at 3.2 lumens.

In Stock & Ready To Ship!
Current Stock:Only left:
This item is sold in multiples of 10
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

Compact LED T1-3/4 midget flange base bulb with selectable 24-28VAC/DC voltage, emitting white light at 3.2 lumens.

Key Features and Benefits

  • Compact T1-3/4 bulb size
  • Midget flanged (SX6s) base
  • Selectable 24-28VAC/DC voltage
  • Emits white light
  • Long lifespan of 30,000 hours
  • Clear lens with 40° viewing angle
  • High brightness of 9,000-12,000 mcd at 20mA

Specifications

  • Voltage Rating: 24-28VAC/DC
  • Current: 18mA
  • Base Type: Midget Flanged (SX6s)
  • Bulb Type: T1-3/4
  • Maximum Overall Length (MOL): 0.63 inches / 16.00 mm
  • Maximum Overall Diameter (MOD): 0.24 inches / 6.00 mm
  • Lumens: 3.2
  • Emitted Color: White
  • Lens Color: Clear
  • Viewing Angle: 40°
  • Brightness: 9,000-12,000 mcd at 20mA
  • Rated Life: 30,000 hours
  • Equivalent to: 327, 376, 385, 387, 7341

Common Uses

Ideal for use in indicator lights, panel lighting, and other applications requiring a compact, reliable, and long-lasting light source.
