Introducing the LRD Series LED Architectural Recessed Lights

Welcome to the next level of lighting innovation with the LRD Series LED Architectural Recessed Lights. This cutting-edge lighting solution features a multiple recessed light cluster with 3 slots and a conveniently selectable color temperature. Perfectly designed for both residential and commercial applications, the LRD series seamlessly blends versatility with energy efficiency.

Key Features and Benefits

Selectable Color Temperature: Adjustable between 2700K, 3000K, 3500K, 4000K, and 5000K.
Adjustable Lumen Output: Delivers 700 lumens.
Efficacy: Efficiency of up to 70 LM/W.
Dimmable: Smooth dimming down to 10% using any standard TRIAC LED dimmer.
Longevity: Impressive lifespan of 50,000 hours.
High CRI: Superior color accuracy with a CRI rating of >90.
Focused Illumination: 30° beam angle for targeted lighting.
Complete Setup: Junction box included with the fixture.
Durability: Constructed from die-cast aluminum with a white powder coat finish.
Type IC Rated: Safe for direct contact with insulation, requiring no additional housing.
Environmental Protection: Designed for damp locations only.
Warranty: Backed by a 5-year manufacturer’s warranty.

Technical Specifications

Voltage: 120VAC.
Wattage: 10W.
Power Factor: >0.90.
Operating Temperature: Rated at 104°F.
Type IC: Approved for direct contact with insulation.

Common Uses

The LRD Series LED Architectural Recessed Lights are ideal for both new and retrofit residential and commercial constructions, making it a versatile choice suitable for a multitude of lighting scenarios.

RESOURCES AND DOWNLOADS

LED Architectural Recessed Lights Spec Sheet

Westgate Resources and Downloads

Details

Beam Angle:	30°
CRI:	90
Color Temperature:	2700K\|3000K\|3500K\|4000K\|5000K
Compliance & Warranty:	Damp Location\|5 Year Warranty\|ETL Listed
Country of Origin:	CHINA
Dimming Type:	Phase
Finish / Color:	White
Housing Material:	Aluminum
Item Height (Inch):	4.29133519685039
Item Length (Inch):	13.19045
Item Weight (LBS):	1.9023
Item Width (Inch):	6.37944
L70 Expected Life (hours):	50,000hr
LED Type:	LED
Lens Material:	PC Lens
Lumen Output:	2100
Operating Temperature:	104°F MAX
Power Factor:	0.9
Ships From:	CA
Special Features:	Selectable CCT
Voltage:	120V
Wattage:	30W
