Lum-Tech FRG Series 3" Floating Round Gimbal Downlight, 8W, 700lm, 120-277V, 5CCT, White Trim, Triac or 0-10V Dimmable

By Lum-Tech Lighting
Lum-Tech FRG Series 3" Floating Round Gimbal Downlight, 8W, 700lm, 120-277V, 5CCT, White Trim, Triac or 0-10V Dimmable
Lum-Tech FRG Series 3" Floating Round Gimbal Downlight, 8W, 700lm, 120-277V, 5CCT, White Trim, Triac or 0-10V Dimmable
Lum-Tech FRG Series 3" Floating Round Gimbal Downlight, 8W, 700lm, 120-277V, 5CCT, White Trim, Triac or 0-10V Dimmable
Lum-Tech FRG Series 3" Floating Round Gimbal Downlight, 8W, 700lm, 120-277V, 5CCT, White Trim, Triac or 0-10V Dimmable

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Lum-Tech FRG Series 3" Floating Round Gimbal Downlight, 8W, 700lm, 120-277V, 5CCT, White Trim, Triac or 0-10V Dimmable

$67.20
  • SKU: LT-LTG-00820
  • MPN: LTG-00820

Quick Overview

3" adjustable LED floating round gimbal downlight for residential and commercial ceilings, featuring 8W power, 700 lumens, 120-277V input, selectable 2700K-5000K CCT, 90+ CRI, and Triac/0-10V dimming down to 5%.

ETL Listed
Title 24 Compliant
JA8 Compliant
WET RATED
WARRANTY 3 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Lum-Tech FRG Series 3" Floating Round Gimbal Downlight is a compact, high-performance recessed fixture designed for directional accent and general illumination. As part of Lum-Tech’s versatile FRG lineup, it combines field-selectable color temperature, smooth dimming, and adjustable aiming for flexible lighting design.

Key Features and Benefits

  • 5-CCT selectable output (2700K/3000K/3500K/4100K/5000K) for easy on-site color tuning
  • Gimbal design with 360° rotation and 90° swivel for precise beam aiming
  • Dimming down to 5% with Triac or 0-10V controls for layered lighting scenes
  • Wet location and airtight rated construction for broader installation versatility
  • JA8 and Title 24 compliant with ETL Listed and FCC compliance for code-ready projects
  • Backed by a 3-year warranty for dependable long-term use

Specifications

  • Lumen Output: 700
  • Wattage: 8W
  • Voltage: 120-277V
  • CRI: 90+
  • Beam Angle: 40° (default)
  • Cutout: 2.95"
  • Outside Diameter: 3.47"
  • Height: 1.54"
  • Output Current: 175mA
  • Output Voltage Range: 33-38V
  • Wire Space: 7.2 sq in

Common Uses

Ideal for residential living areas, hospitality spaces, retail displays, corridors, and other interior or protected exterior ceiling applications where adjustable recessed lighting and selectable CCT are needed.

RESOURCES AND DOWNLOADS

Lum-Tech FRG Series 3" Floating Round Gimbal Downlight Spec Sheet
