MaxLite 4' UL Type-B Bypass T8 LED Tube, 10W, 4000K, Single/Double-Ended, Inner Coated Glass

By MaxLite
Clearance

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

MaxLite 4' UL Type-B Bypass T8 LED Tube, 10W, 4000K, Single/Double-Ended, Inner Coated Glass

Now: $6.30
Reg: $13.67
Sale 54%
You save $ 7.37
  • SKU: MX-L10T8SDE440-CG
  • MPN: L10T8SDE440-CG

Quick Overview

4' Type-B LED T8 tube for ballast-bypass retrofits in enclosed fixtures. Delivers 1,600-1,650 lumens at 10W, 4000K, 120-277V, CRI 80+, 210° beam, and 50,000-hour L70 life.

UL Listed
DLC Standard
NSF Listed
DAMP RATED
WARRANTY 5 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
This item is sold in multiples of 25
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The MaxLite 4' Bypass T8 UL Type-B lamp is designed for fast fluorescent-to-LED upgrades in commercial and institutional spaces. As part of MaxLite’s single/double-ended power series, it simplifies inventory and installation while reducing energy use and maintenance costs.

Key Features and Benefits

  • Dual wiring flexibility supports both single-ended and double-ended ballast-bypass installations
  • High-efficiency LED performance helps cut energy consumption versus 32W fluorescent lamps
  • Built for enclosed luminaires with dependable operation in damp environments
  • Long 50,000-hour L70 life reduces relamping frequency and labor costs
  • Backed by a 5-year limited warranty for added project confidence
  • Certified for broad commercial use, including DLC Standard, cUL Listed, FCC, RoHS, and NSF Listed compliance

Specifications

  • Lumen Output: 1600-1650
  • Wattage: 10W
  • Voltage: 120-277V
  • Color Temperature: 4000K
  • CRI: 80
  • Dimming Type: 0-10V (with external dimming module)
  • Beam Angle: 210°
  • Power Factor: 0.9
  • Frequency: 50/60
  • Rated Life (L70): 50000 hours
  • Operating Temperature: -20°C to 45°C
  • Base: G13

Common Uses

Ideal for offices, schools, healthcare support areas, retail back-of-house, and other facilities upgrading 4' fluorescent troffers and strip fixtures to LED. Suitable for enclosed fixtures in damp-location applications.
