MaxLite ArcMax Volumetric Troffer, 1'x4', Dimmable, 16W/20W/30W Selectable, 3500K/4000K/5000K Selectable, Controls Ready

By MaxLite
Clearance

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

MaxLite ArcMax Volumetric Troffer, 1'x4', Dimmable, 16W/20W/30W Selectable, 3500K/4000K/5000K Selectable, Controls Ready

Now: $26.15
Reg: $56.67
Sale 54%
You save $ 30.52
  • SKU: MX-MLVT14D16WCSCR
  • MPN: MLVT14D16WCSCR

Quick Overview

1'x4' ArcMax LED volumetric troffer with selectable 16W/20W/30W and 3500K/4000K/5000K CCT, 0-10V dimming, 120-277V input, DLC Premium qualification, and 100,000-hour L70 life for commercial interiors.

UL Listed
DLC Premium
DAMP RATED
IC RATED
WARRANTY 10 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The MaxLite ArcMax MLVT14D16WCSCR is a control-ready 1'x4' volumetric LED troffer designed to modernize fluorescent troffer applications in new construction and retrofit projects. As part of MaxLite’s ArcMax lineup, it combines field-selectable wattage and CCT flexibility with high visual comfort and long-life performance for demanding commercial spaces.

Key Features and Benefits

  • Field-adjustable output lets you choose 16W, 20W, or 30W to match light levels and energy goals.
  • Selectable 3500K, 4000K, or 5000K CCT supports varied tasks and interior design preferences.
  • Controls Ready design enables fast plug-and-play integration with compatible c-Max control nodes.
  • 0-10V dimming capability supports smooth light control and additional energy savings.
  • Qualified for DLC Premium and listed cULus/FCC for confidence in performance and compliance.
  • Backed by a 10-year warranty for long-term reliability in commercial installations.

Specifications

  • Size: 1'x4'
  • Lumen Output: 1968/2000/2000 lm (16W), 2460/2500/2500 lm (20W), 3690/3750/3750 lm (30W)
  • Input Voltage: 120-277V, 50/60Hz
  • CRI: ≥80
  • L70 Rated Life: ≥100,000 hours
  • Power Factor: >0.9
  • Operating Temperature: -4°F to 104°F (-20°C to 40°C)
  • Environment: Damp/Dry location, IC rated

Common Uses

Ideal for offices, schools, healthcare facilities, hospitality spaces, and retail interiors where uniform low-glare illumination, controllability, and long service life are priorities.
