120/277V 6in Baffle Round Slim Panel Light, 900LM 30K, 90 Cri, 0-10V, UL Es JA8

By Westgate Manufacturing

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

120/277V 6in Baffle Round Slim Panel Light, 900LM 30K, 90 Cri, 0-10V, UL Es JA8

$14.05 - $31.30
MSRP: $15.85 - $35.32
You save $ 1.80 (11%)
  • SKU: WM-RSLC6-BF

Quick Overview

120/277V 6in Baffle Round Slim Panel Light, 900LM 30K, 90 Cri, 0-10V, UL Es JA8 (wattage: 15W; lumens: 1200LM; CCT: 3000K; 4000K; voltage: 120-277V; finish: White)

Availability: 1 business day
In Stock & Ready To Ship!
Current Stock:Only left:
Free shipping on this item
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

Upgrade your lighting with the RDL Series 12 Watt LED Commercial Slim Recessed Baffle Lights, a perfect blend of performance and efficiency. This high-quality fixture delivers 900 lumens and is available in a choice of 3000K, 4000K, or 5000K color temperatures (CCT) to match your lighting needs. Constructed with die-cast aluminum and finished with a white powder coat, it boasts a rated life of up to 50,000 hours and a 7-year limited warranty, guaranteeing long-lasting reliability.

Ideal for both new and retrofit residential and commercial applications, this 6” slim recessed baffle light is designed to meet all your lighting requirements with ease.

FEATURES

  • White Translucent Acrylic for optimal light diffusion.
  • Robust Die-Cast Aluminum with a durable powder coat finish.
  • Comes with a junction box for seamless installation.
  • Backed by a 7-Year Warranty for peace of mind.

ELECTRICAL

  • Operates at 120-277V for versatile compatibility.
  • Energy-efficient with a low Wattage of 12W.
  • High Power Factor of >0.9 for superior efficiency.
  • Outstanding Efficacy rated at 79 LPW.

MECHANICAL

  • Constructed from Die-Cast Aluminum with a white powder coat finish for durability.
  • Includes a junction box with a thickness of 1-3/8”.
  • Features a 24” DC cord from the driver box to the fixture.
  • Handles a wide Operating Temperature range from -4°F to 104°F.
  • Designed for recessed mounting, making it suitable for a variety of applications.
  • 5-Year Warranty, indicating high quality and durability.
  • Rated suitable for Wet locations.

LIGHTING

  • 0-10V Dimmable feature for customizable lighting.
  • Produces 900 Lumens.
  • Available in multiple Color Temperatures: 3000K, 4000K, and 5000K.
  • High Color Rendering Index (CRI) of ≥ 90 for vibrant and true color representation.
  • Impressive lifespan of 50,000 hours, ensuring longevity.
  • Wide Beam Angle of 110° for extensive light coverage.

APPLICATIONS

  • Perfect for both new and existing Residential setups.
  • Suitable for various Commercial Constructions.
