SCX Series, 1FT, 10W, Multi-CCT, Dimmable, Up Light Option

By Westgate Manufacturing

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

SCX Series, 1FT, 10W, Multi-CCT, Dimmable, Up Light Option

$133.74
MSRP: $150.78
You save $ 17.04 (11%)
  • SKU: WM-SCX-1FT-10W-MCT4-D-LUV
  • MPN: SCX-1FT-10W-MCT4-D-LUV

Quick Overview

SCX Series, 1FT, 10W, Multi-CCT, Dimmable, Up Light Option (wattage: 10W; lumens: 1100LM; CCT: 30K/35K/40K/50K; voltage: 120-277V; finish: White)

WARRANTY 5 YEARS
IP54
Availability: 1 business day
In Stock & Ready To Ship!
Current Stock:Only left:
Free shipping on this item
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The SCX Series from Westgate Manufacturing offers a superior architectural lighting solution, perfect for modern lighting needs. With its sleek design and high performance, it's ideal for enhancing any indoor space.

Key Features and Benefits

  • Selectable color temperatures: 3000K, 3500K, 4000K, 5000K
  • Adjustable lumen output: 1100LM
  • High efficacy: 110 LPW
  • Long lifespan: 50,000 hours
  • Dimmable: 0-10V dimming
  • Up light option available
  • Polished aluminum louver lens for direct lighting
  • Low profile modern design with custom color options
  • IP54 rated for protection against dust and water
  • 5-year warranty
  • Optional recessed and wall mounting kits available

Specifications

  • Voltage: 120-277VAC 50/60Hz
  • Wattage: 10W
  • Power Factor: >0.95
  • Total Harmonic Distortion: ≤ 20%
  • Color Rendering Index: CRI ≥ 80
  • Beam Angle: 104.8°(H) x 100.5°(V)
  • Operating Temperature: -13°F~104°F

Common Uses

Ideal for offices, hotels, corridors, saloons, libraries, meeting rooms, conference halls, retail locations, lobbies, reception areas, hallways, educational facilities, and restaurants.

RESOURCES AND DOWNLOADS

SCX Series Spec Sheet

Westgate Resources and Downloads
