Westgate SCX Series Linear Architectural Light, 4FT, 40W, 3000K/3500K/4000K/5000K, 0-10V Dimmable, Black

By Westgate Manufacturing

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Westgate SCX Series Linear Architectural Light, 4FT, 40W, 3000K/3500K/4000K/5000K, 0-10V Dimmable, Black

$185.55
MSRP: $206.78
You save $ 21.23 (10%)
  • SKU: WM-SCX-4FT-40W-MCT4-D-BK
  • UPC: 840378303637
  • MPN: SCX-4FT-40W-MCT4-D-BK

Quick Overview

4' architectural linear LED fixture for modern indoor spaces, delivering 4400 lumens at 40W with selectable 3000K/3500K/4000K/5000K, 0-10V dimming, IP54 rating, and versatile surface, suspended, wall, or recessed mounting.

UL Listed
WARRANTY 5 YEARS
IP54
Availability: 1 business day
In Stock & Ready To Ship!
Current Stock:Only left: 67
Free shipping on this item
Call, chat, or email for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Westgate SCX Series 4' linear architectural fixture is a premium commercial lighting solution designed for clean aesthetics and flexible layout design. This 40W model combines selectable CCT, smooth dimming, and high efficacy to support modern office, hospitality, and institutional interiors. As part of Westgate’s modular SCX lineup, it enables seamless, professional-grade linear lighting installations.

Key Features and Benefits

  • Selectable 4-CCT output (3000K/3500K/4000K/5000K) for easy on-site lighting customization
  • 0-10V dimming capability for enhanced control, comfort, and energy savings
  • Architectural low-profile form with matte black aluminum housing for a modern finish
  • Seamless linkable system with compatibility for T/L/X/Y/corner modules and multiple mounting styles
  • UL Listed construction with 5-year warranty for dependable commercial performance
  • IP54-rated design helps protect fixture performance in demanding indoor environments

Specifications

  • Lumen Output: 4400
  • Wattage: 40W
  • Voltage: 120-277V
  • Frequency: 50/60
  • Efficacy: 110 lm/W
  • CRI: 80+
  • Power Factor: >0.95
  • THD: ≤20%
  • Beam Angle: 104.8°(H) x 100.5°(V)
  • Rated Life: 50000 hours
  • Dimensions: 47 2/5"(L) x 2 6/8"(W) x 3 3/8"(H)
  • Operating Temperature: -13°F to 104°F

Common Uses

Ideal for offices, conference rooms, lobbies, reception areas, corridors, libraries, hotels, restaurants, retail spaces, and other indoor commercial applications requiring modern linear architectural illumination.
