Unify Half Round Down Wall Sconce, 3L/5L/8L Lumen Selectable, 120-277V, CCT Selectable, Bronze

By Industrial Lighting Products
Unify Half Round Down Wall Sconce, 3L/5L/8L Lumen Selectable, 120-277V, CCT Selectable, Bronze

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Unify Half Round Down Wall Sconce, 3L/5L/8L Lumen Selectable, 120-277V, CCT Selectable, Bronze

$413.95
  • SKU: ILP-UWRD-3L/5L/8L-U-CCTS-BRZ
  • MPN: UWRD-3L/5L/8L-U-CCTS-BRZ

Quick Overview

Architectural half-round LED wall sconce for exterior applications with selectable 3L/5L/8L lumen packages, 3000K/4000K/5000K CCT, 0-10V dimming, IP65 wet-location rating, and durable die-cast aluminum construction.

UL Listed
Title 24 Compliant
WET RATED
WARRANTY 5 YEARS
IP65
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The ILP Unify Architectural Wall Mount series delivers modern exterior illumination with a compact half-round profile and dependable commercial-grade performance. This UWRD configuration is designed for downlight distribution and combines selectable lumen output with selectable CCT for flexible project deployment. Built for demanding outdoor environments, it is a key solution in ILP’s architectural wall pack lineup for multi-use commercial sites.

Key Features and Benefits

  • Field-selectable lumen output (3L/5L/8L) helps match light levels to site needs while simplifying SKU management.
  • Selectable 3000K/4000K/5000K color temperatures provide adaptable visual comfort across varied exterior applications.
  • Rugged die-cast aluminum housing with tempered glass lens supports long-term durability in harsh weather conditions.
  • 0-10V dimming capability and optional PIR bi-level control support energy-saving lighting strategies.
  • Certified for demanding projects with UL Listed wet-location compliance, IP65 protection, LM-79/LM-80 testing, RoHS, FCC, and Title 24 compliance.
  • Backed by a 5-year warranty for added confidence in commercial installations.

Specifications

  • Lumen Output: 3072 | 3349 | 3124 | 5502 | 5998 | 5595 | 7855 | 8568 | 7993
  • Wattage: 25W | 44.7W | 64.5W
  • Voltage: 120-277V
  • Color Temperature: 3000K | 4000K | 5000K
  • CRI: 70
  • Efficacy: 122-138 lm/W
  • Rated Life (L70): 60000 hours (calculated up to 100000 hours)
  • Operating Temperature: -40 to 104 (-40 to 40 )
  • Dimming: 0-10V to 10%
  • Frequency: 50/60 Hz
  • IP Rating: IP65
  • Finish: Bronze

Common Uses

Ideal for exterior wall lighting at building entrances, pedestrian walkways, retail centers, parking areas, multi-family properties, schools, offices, industrial facilities, and storage sites where reliable architectural illumination is required.

RESOURCES AND DOWNLOADS

Unify Half Round Down Wall Sconce Spec Sheet
