E26 medium base LED corn lamp, 36 watts, 4,500-5,580 lumens, available in 3000K, 5000K color temperature (CCT), up to 50,000 hours rated life, suitable for damp locations, 5 years limited warranty.
LED Corn Lamp suitable for supermarkets, warehouses, garages, home, offices, hotels, hospitals, schools, high bay retrofitting.
FEATURES
- E26 medium Base
- 5-Year Warranty
- Housing: PC + Aluminum
- 50,000 Hours Rated Life
ELECTRICAL
- Voltage: 120-277V AC 50/60Hz
- Wattage: 36W
- Power Factor: >0.9
- AC Direct / Bypass Existing Ballast
- THD: ≤20%
- Efficacy: 125/ 155LPW
MECHANICAL
- PC and Aluminum Housing and Sealant Pouring for Whole Driver
- Meet 4KV surge immunity level
- Operating temperature: -40°F to 176°F
- Minimum Enclosed Space Dimension: 15.0”(H) x 7.9”(D) and 928 Cubic in
- Suitable for Damp Location
LIGHTING
- LED SMD type: Edison 2835
- Total Lumens: 4500LM/ 5580LM
- Color temperature: 5000K/3000K
- Color Rendering Index: CRI ≥ 80
- Beam angle: 360°
APPLICATIONS
- LED Corn Lamp suitable for supermarkets, warehouses, garages, home, offices, hotels, hospitals, schools, highbay retorfitting.
RESOURCES AND DOWNLOADS
| SKU | WM-CL-EHL-36W-E26 |
|---|---|
| Weight | 8.00 LBS |
| Light Source | LED |
| Fixture Size | 7.55"x3.34" |
| Lumen Output | 4,500-5,580lm |
| L70 Expected Life (hours) | 50,000hrs |
| Luminaire Efficacy Rating (LER) | 125lm/w, 155lm/w |
| Color Rendering Index (CRI) | >80 |
| Driver Type | 120-277VAC |
| Color Temperature (CCT) | 3000K, 5000K |
| Total Input Watts | 36W |
