Universal Light Bar Kit, 2', 1760lm|1800lm, 3500K|5000K, 120-277V, 1 Light Bar

By Green Creative

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Universal Light Bar Kit, 2', 1760lm|1800lm, 3500K|5000K, 120-277V, 1 Light Bar

$32.30
  • SKU: GC-20LB/2F/8/U/A1
  • MPN: 20LB/2F/8/U/A1

Quick Overview

Cost-effective 2' LED retrofit light bar kit with 1760-1800 lumens, 3500K/5000K options, 120-277V input, 0-10V dimming, and up to 100,000-hour L70 life for enclosed and damp-rated fixtures.

ETL Listed
DLC Standard
DAMP RATED
WARRANTY 5 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Universal Light Bar Kit from GREENCREATIVE is a versatile linear retrofit solution designed to modernize existing fluorescent fixtures with efficient LED performance. As part of the brand’s retrofit lineup, it combines easy installation features with selectable output options to reduce labor and energy costs. This 2' single-bar configuration is ideal for upgrading enclosed fixtures in commercial spaces.

Key Features and Benefits

  • Quick-connect light bar design speeds up retrofit installation and minimizes downtime
  • Magnet-assisted mounting with included self-tapping screws helps simplify alignment and secure placement
  • Field-lumen selectable driver supports flexible light level tuning for different application needs
  • 0-10V dimming capability (down to 10%) enables better energy control and visual comfort
  • Built for enclosed fixtures and damp locations for broader retrofit compatibility
  • Backed by a 5-year limited warranty, with optional 10-year extended coverage
  • Certified with ETL Listed, FCC, and DLC Standard qualifications for code and rebate readiness

Specifications

  • Lumen Output: 1760|1800
  • Wattage: 11W
  • Voltage: 120-277V
  • Color Temperature: 3500K|5000K
  • Efficacy (lm/W): 160|164
  • Rated Life (L70): 100000
  • Dimming Type: 0-10V
  • Max Ambient Temperature: 122°F (50°C)
  • Primary Material: Plastic
  • Lens Material: Frosted Polycarbonate
  • Form Factor: Linear
  • Damp Rated: true

Common Uses

Commonly used for commercial and industrial fluorescent-to-LED retrofits in utility areas, back-of-house spaces, storage rooms, and similar indoor environments where enclosed fixture compatibility and dependable efficiency are required.

RESOURCES AND DOWNLOADS

Universal Light Bar Kit Spec Sheet
