Lotus Tangra 3" Gimbal Square Invisible Trim, 5CCT 2700K/3000K/3500K/4000K/5000K, CRI95

By Lotus LED Lights
Lotus Tangra 3" Gimbal Square Invisible Trim, 5CCT 2700K/3000K/3500K/4000K/5000K, CRI95
Lotus Tangra 3" Gimbal Square Invisible Trim, 5CCT 2700K/3000K/3500K/4000K/5000K, CRI95
Lotus Tangra 3" Gimbal Square Invisible Trim, 5CCT 2700K/3000K/3500K/4000K/5000K, CRI95
Lotus Tangra 3" Gimbal Square Invisible Trim, 5CCT 2700K/3000K/3500K/4000K/5000K, CRI95

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Lotus Tangra 3" Gimbal Square Invisible Trim, 5CCT 2700K/3000K/3500K/4000K/5000K, CRI95

$151.95
  • SKU: LLL-L3G-SIT-5C95
  • MPN: L3G-SIT-5C95

Quick Overview

3" trimless gimbal recessed fixture with up to 1600 lm, selectable 11W/15W power, 20° tilt and 360° rotation, and 5CCT CRI95 tuning for task, sloped ceiling, and wall-wash applications.

IP54
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Lotus Tangra L3G-SIT series is a premium 3" gimbal square invisible trim fixture engineered for high-end architectural recessed lighting. Built in Canada with a cast aluminum body and advanced optics, it delivers flexible aiming, high color quality, and modular driver options for residential and commercial projects.

Key Features and Benefits

  • Trimless 3" square gimbal design creates a clean, modern ceiling appearance.
  • Precision aiming with 20° tilt and full 360° rotation for accent, task, and wall-wash lighting.
  • Selectable 11W/15W operation with output up to 1600 lumens for adaptable performance.
  • Available with Triac or 0-10V dimming driver options to match control requirements.
  • Certified cETLus and FCC, with Type IC, Air Tight, Open Plenum, and Wet Location IP54 ratings.
  • Backed by Lotus long-term line support plus 5-year warranty coverage.

Specifications

  • Lumen Output: up to 1600
  • Wattage: 11W/15W selectable
  • Voltage: 120V AC (Triac driver) or 120-347V AC (0-10V driver)
  • Color Temperature: 2700K/3000K/3500K/4000K/5000K (5CCT)
  • Optics options: Reflector clear glass (RC), semi-frosted (RS), frosted (RF), lens white (LW), lens black (LB)
  • CRI: 95
  • Beam Angle: 20°/24°/36°/50°/60°
  • Fixture Input: 20-40V DC, max 350mA constant current
  • Max Ambient Temperature: -40°F (-40°C) to +113°F (+45°C)
  • Rated Life: 50,000 hours at 70% lumen maintenance

Common Uses

Ideal for task lighting, sloped ceilings up to 20°, and wall washing in residential, hospitality, retail, and other architectural interiors where discreet trimless aesthetics and precise beam control are required.

RESOURCES AND DOWNLOADS

Lotus Tangra 3" Gimbal Square Invisible Trim Spec Sheet
