Small flood light with knuckle, 10W/ 15W/ 20W/ 30W selectable, 4,080 lumens maximum, available in 3000K, 4000K or 5000K color temperature (CCT), up to 70,000 hours rated life, suitable for wet locations, 7 years limited warranty.
Ideal for general site lighting, alleys, loading docks, doorway, pathway, and parking areas.
FEATURES
- DLC Premium & LED High-Lumen Flood lights
- Solid State Lighting Technology for Long Life
- No Maintenance Needed and High-Efficiency
- 70,000 Hours Rated Life
- 7-Year Warranty
- Optic Lens Type: III
- Multi-Power - The Switch is on the Bottom of the Fixture
ELECTRICAL
- Voltage: 120~277V AC/50~60 Hz
- Wattage: Selectable Wattages (10W/ 15W/ 20W/ 30W)
- Power Factor: >0.9
- Efficacy: 130 LPW
MECHANICAL
- Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
- LED: Philips Lumileds Luxeon 2835 High Flux LED
- Solid State Lighting technology for long life, no Maintenance needed and High-Efficiency
- High Conductive Aluminum LED Board
- 90° Adjustable 1/2” Knuckle Mount
- IP Rating: IP65
- Operating Temperature: -40°F to 104°F
- Suitable for Wet Locations
LIGHTING
- Dimming: 0~10V Dimmable
- Optic Lens Type: III
- Cord type: 13” #18 AWG stranded wires
- Total Lumens: 4080LM Max
- Color Temperature: 3000K/ 4000K/ 5000K
- Color Rendering Index: ≥ 82
- Beam Angle: 120°X 90°
SKU | WM-LFX-SM-10-30W-KN |
---|---|
Weight | 16.00 LBS |
Light Source | LED |
Fixture Size | 9" x 6 7/8" x 2" |
Driver Type | 120-277VAC |
Lumen Output | 4,080lm max. |
L70 Expected Life (hours) | 70,000hrs. |
Color Temperature (CCT) | 3000K,4000K,5000K |
Total Input Watts | 10W/15W/20W/30W |
