FLOOD/AREA Ligh,t 120-277V

By Westgate Manufacturing

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

FLOOD/AREA Ligh,t 120-277V

$70.74
MSRP: $79.78
You save $ 9.04 (11%)
  • SKU: WM-LFX-SM-10-30W-KN
  • MPN: LFX-SM-10-30W-KN

Quick Overview

FLOOD/AREA Ligh,t 120-277V (wattage: 10W/15W/20W/30W; lumens: 130LM/W; efficacy: 130LM/W; CCT: 3000K; 4000K; 5000K; voltage: 120-277V)

UL Listed
DLC Premium
WARRANTY 7 YEARS
IP65
Availability: 1 business day
In Stock & Ready To Ship!
Current Stock:Only left:
Free shipping on this item
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

Versatile Small Flood Light with Knuckle Mount

The WM-LFX-SM-10-30W-KN is a small flood light with a selectable wattage ranging from 10W to 30W, delivering a maximum of 4,080 lumens. Available in three different color temperatures (3000K, 4000K, 5000K), this flood light is built to last up to 70,000 hours and is ideal for general site lighting, alleys, loading docks, doorways, pathways, and parking areas. It also comes with a 7-year limited warranty, ensuring peace of mind and reliability.

Key Features

  • DLC Premium & LED High-Lumen Flood Lights
  • Solid State Lighting Technology for Long Life
  • No Maintenance Needed and High-Efficiency
  • 70,000 Hours Rated Life
  • 7-Year Warranty
  • Optic Lens Type: III
  • Multi-Power - The Switch is on the Bottom of the Fixture

Electrical Specifications

  • Voltage: 120~277V AC / 50~60 Hz
  • Wattage: Selectable Wattages (10W / 15W / 20W / 30W)
  • Power Factor: >0.9
  • Efficacy: 130 LPW

Mechanical Features

  • Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
  • LED: Philips Lumileds Luxeon 2835 High Flux LED
  • High Conductive Aluminum LED Board
  • 90° Adjustable 1/2” Knuckle Mount
  • IP Rating: IP65
  • Operating Temperature: -40°F to 104°F
  • Suitable for Wet Locations

Lighting Specifications

  • Dimming: 0~10V Dimmable
  • Optic Lens Type: III
  • Cord type: 13” #18 AWG stranded wires
  • Total Lumens: 4080LM Max
  • Color Temperature: 3000K / 4000K / 5000K
  • Color Rendering Index: ≥ 82
  • Beam Angle: 120°X 90°

RESOURCES AND DOWNLOADS

Small Flood/Area Light Spec Sheet
