ProLED Select Compact Linear High Bay 4, Lumen Selectable 38600|43300|47700, Wattage Selectable 240W|280W|320W, Color Selectable 3500K|4000K|5000K, 120-277V, Adjustable Beam 45°x100°|65°x90°|90°x90°, Z10 Receptacle

By Halco Lighting Technologies

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

ProLED Select Compact Linear High Bay 4, Lumen Selectable 38600|43300|47700, Wattage Selectable 240W|280W|320W, Color Selectable 3500K|4000K|5000K, 120-277V, Adjustable Beam 45°x100°|65°x90°|90°x90°, Z10 Receptacle

$193.80
  • SKU: HLT-CLHB-4-LS-CS-U
  • MPN: CLHB-4-LS-CS-U

Quick Overview

Compact linear LED high bay for warehouses and large indoor spaces with selectable 240W/280W/320W, 38,600-47,700 lumens, 3500K/4000K/5000K, adjustable beam angles, and 0-10V dimming.

UL Listed
DAMP RATED
WARRANTY 5 YEARS
IP20
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Halco ProLED Select Compact Linear High Bay Series is engineered for high-ceiling commercial and industrial interiors that demand strong output and flexible performance. This CLHB-4 configuration delivers top-end lumen packages in a compact form factor, making it a key option in Halco’s high bay lineup for efficient, adaptable illumination.

Key Features and Benefits

  • Field-selectable wattage, lumen output, CCT, and beam distribution for easier on-site tuning
  • Integrated Zhaga Z-10 receptacle supports plug-and-play sensor and Bluetooth control upgrades
  • Durable die-cast aluminum body improves thermal management and long-term reliability
  • 0-10V dimming capability helps reduce energy use and optimize light levels
  • DLC Premium, cULus listed, FCC, and RoHS compliant for broad project acceptance
  • Backed by a 5-year limited warranty for added confidence in demanding applications

Specifications

  • Lumen Output: 38600|43300|47700
  • Wattage: 240W|280W|320W
  • Voltage: 120-277V
  • Color Temperature: 3500K|4000K|5000K
  • CRI: 80
  • Beam Angle: 45°x100°|65°x90°|90°x90°
  • Efficacy (lm/W): 157-166
  • Rated Life (L70): 100000+
  • Power Factor: >0.9
  • Operating Temperature: -40°C to 55°C
  • IP Rating: IP20
  • Mounting: Chain and V-hook (standard)
  • Weight: 10.8 lbs

Common Uses

Ideal for warehouses, gymnasiums, manufacturing areas, distribution centers, and large-format retail spaces where high output, controllability, and dependable indoor performance are required.
