TruBlu Mesh Passive Infrared Sensor-Controller, 1-Channel, 0-10V, 12-24VDC, 3.5mm Audio Jack, Photocell, High Bay Lens, Bluetooth Mesh, Black

By Halco Lighting Technologies
TruBlu Mesh Passive Infrared Sensor-Controller, 1-Channel, 0-10V, 12-24VDC, 3.5mm Audio Jack, Photocell, High Bay Lens, Bluetooth Mesh, Black
TruBlu Mesh Passive Infrared Sensor-Controller, 1-Channel, 0-10V, 12-24VDC, 3.5mm Audio Jack, Photocell, High Bay Lens, Bluetooth Mesh, Black
TruBlu Mesh Passive Infrared Sensor-Controller, 1-Channel, 0-10V, 12-24VDC, 3.5mm Audio Jack, Photocell, High Bay Lens, Bluetooth Mesh, Black
TruBlu Mesh Passive Infrared Sensor-Controller, 1-Channel, 0-10V, 12-24VDC, 3.5mm Audio Jack, Photocell, High Bay Lens, Bluetooth Mesh, Black

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

TruBlu Mesh Passive Infrared Sensor-Controller, 1-Channel, 0-10V, 12-24VDC, 3.5mm Audio Jack, Photocell, High Bay Lens, Bluetooth Mesh, Black

$114.90
  • SKU: HLT-PSC-JAV-I-11H-BLE-SR-BK
  • MPN: PSC-JAV-I-11H-BLE-SR-BK

Quick Overview

Wireless PIR sensor-controller for high/low bay fixtures with 0-10V dimming, integrated photocell, Bluetooth Mesh control, and 12-24VDC input for indoor/outdoor applications.

DLC Standard
WARRANTY 5 YEARS
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Halco TruBlu™ Mesh Passive Infrared Sensor-Controller is a compact, fixture-mounted wireless control solution designed for modern high bay and low bay lighting systems. As part of Halco’s TruBlu controls lineup, it combines PIR occupancy sensing, daylight response, and Bluetooth Mesh networking to simplify intelligent lighting control without hardwired communication.

Key Features and Benefits

  • Bluetooth® NLC certified platform supports multi-vendor interoperability for scalable smart lighting projects
  • Integrated PIR motion sensing and photocell enable occupancy-based and ambient light-based control strategies
  • Single-channel 0-10V continuous dimming supports high-end trim, zoning, and energy-saving light level control
  • Fixture-ready 3.5mm audio jack base and quick connector streamline installation and commissioning
  • Reliable operation in demanding environments from -20°C to 45°C for indoor and outdoor use
  • DLC Listed design helps support utility rebate and code-driven project requirements

Specifications

  • Input Voltage: 12-24VDC
  • Current Consumption: 20mA max
  • Dimming Output: 0-10VDC, 1-channel
  • Mounting Height: 20'-40' (6.1-12.2m)
  • Maximum Sensor Coverage: 80' diameter (24.4m)
  • Maximum Bluetooth Range: 100' (30.4m)
  • Lens Type: High Bay Lens (H)
  • Housing Color: Black

Common Uses

Ideal for warehouses, gymnasiums, manufacturing spaces, distribution centers, and other commercial or industrial facilities using high/low bay luminaires that require wireless occupancy and daylight-responsive dimming control.

RESOURCES AND DOWNLOADS

TruBlu Mesh Passive Infrared Sensor-Controller Spec Sheet
