BEAM-ADJ. Wall Pack 90/120/150W 3CCT With Photocell Brz

By Westgate Manufacturing
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze
Westgate WPMAX Series LED Wall Pack, 90W/120W/150W, 13500/18000/20250 lumens, 3000K/4000K/5000K, 120-277V, Bronze

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

BEAM-ADJ. Wall Pack 90/120/150W 3CCT With Photocell Brz

$367.85
MSRP: $407.78
You save $ 39.93 (10%)
  • SKU: WM-WPMAX-90-150W-MCTP
  • MPN: WPMAX-90-150W-MCTP

Quick Overview

BEAM-ADJ. Wall Pack 90/120/150W 3CCT With Photocell Brz (wattage: 90W/120W/150W; lumens: 20250; efficacy: 135LM/W; CCT: 30K/40K/50K; voltage: 120-277V)

UL Listed
DLC Standard
WET RATED
IP65
In Stock & Ready To Ship!
Current Stock:Only left: 77
Free shipping on this item
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Westgate WPMAX Series is a high-performance LED wall pack built for dependable outdoor security and area illumination. Designed as a modern replacement for traditional HID wall packs, it combines selectable wattage and CCT in one fixture for flexible project deployment. Its cutoff-style optical design helps improve visibility while reducing glare and unwanted light spill.

Key Features and Benefits

  • Field-selectable output with multi-watt and multi-CCT switches inside the fixture for easier SKU consolidation
  • Adjustable throw settings (narrow, medium, wide) with selectable Type 2/3/4 lensing for site-specific coverage
  • Durable ADC12 aluminum heat sink and outdoor powder-coated housing for long-term exterior performance
  • Prismatic borosilicate glass lens enhances optical control and fixture durability
  • 0-10V dimming support for energy savings and lighting control integration
  • Certified for safety and performance with UL listing and DLC qualification, backed by a 7-year warranty

Specifications

  • Wattage: 90W/120W/150W
  • Voltage: 120-277V AC, 50/60Hz
  • Lumen Output: 13500lm/18000lm/20250lm (max)
  • Color Temperature: 3000K/4000K/5000K
  • CRI: >70
  • Efficacy: 135 lm/W
  • Rated Life: 70000 hours
  • Power Factor: >0.9
  • Input Current: 0.6A
  • BUG Rating: B2-U3-G3
  • IP Rating: IP65
  • Operating Temperature: -40b0F to 122b0F
  • Dimensions: 13.34"(W) x 8.26"(H) x 5.86"(D)
  • Mounting: Wall mount
  • Conduit Hubs: Four 1/2" hubs (top, both sides, rear)
  • Photocell: Included

Common Uses

Ideal for entrances, courtyards, building perimeters, hotel exteriors, industrial facilities, and general outdoor wall-mounted security lighting applications.

RESOURCES AND DOWNLOADS

Westgate WPMAX Series LED Wall Pack Spec Sheet
