Westgate LLHB Series LED Linear High Bay, 90W|135W|180W, Multi Power, 4000K|5000K, Dimmable, Sensor-Ready, Silver

By Westgate Manufacturing

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Westgate LLHB Series LED Linear High Bay, 90W|135W|180W, Multi Power, 4000K|5000K, Dimmable, Sensor-Ready, Silver

$178.74
MSRP: $201.78
You save $ 23.04 (11%)
  • SKU: WM-LLHB-90-180W-MP-D-SR
  • MPN: LLHB-90-180W-MP-D-SR

Quick Overview

Westgate LLHB Series LED Linear High Bay, 90W|135W|180W, Multi Power, 4000K|5000K, Dimmable, Sensor-Ready, Silver (wattage: 90W/135W/180W; lumens: 24300; efficacy: 135LM/W; CCT: 4000K; 5000K; voltage: 120-277VAC)

WARRANTY 5 YEARS
Availability: 1 business day
In Stock & Ready To Ship!
Current Stock:Only left:
Free shipping on this item
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Westgate LLHB Series LED Linear High Bay is a versatile and energy-efficient solution designed for large indoor spaces. With selectable wattages (90W, 135W, 180W) and color temperatures (4000K, 5000K), this fixture delivers powerful illumination up to 24,300 lumens, making it ideal for warehouses, manufacturing plants, and gymnasiums. Its robust construction, advanced heat dissipation, and sensor-ready design set it apart in the Westgate lineup.

Key Features and Benefits

  • Selectable wattage and color temperature for tailored lighting
  • High efficacy at 135 lumens per watt for energy savings
  • Long 50,000-hour rated life reduces maintenance costs
  • Sensor-ready with pre-installed audio jack for motion sensors
  • Durable steel housing and polycarbonate lens for reliability
  • 0-10V dimmable for flexible lighting control
  • Suitable for damp locations and wide temperature range
  • 5-year warranty for peace of mind

Specifications

  • Lumens: 12,150lm | 18,225lm | 24,300lm
  • Wattage: 90W | 135W | 180W
  • Voltage: 120-277VAC
  • Color Temperature: 4000K | 5000K
  • CRI: >80
  • Dimensions: 46"(L) x 8-7/8"(W) x 2-6/8"(H)
  • Rated Life: 50,000 hours
  • Dimming: 0-10V

Common Uses

Perfect for warehouses, manufacturing plants, distribution centers, industrial facilities, commercial spaces, grocery stores, and gymnasiums—especially where mounting heights range from 10 to 40 feet.
