LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V

By LEDone Distribution
LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V
LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V
LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V
LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V
LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V
LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

LEDone LOC-22TRKT LED Troffer Retrofit Kit, 2x2, 15W/19W/24W/29W, 3500K/4000K/5000K, 120-277V, 0-10V

$72.35
  • SKU: LOD-LOC-22TRKT-MW(15/19/24/29)MCCT(35/40/50)
  • MPN: LOC-22TRKT-MW(15/19/24/29)MCCT(35/40/50)

Quick Overview

Selectable 2x2 LED troffer retrofit kit for commercial interiors, offering 15W/19W/24W/29W and 3500K/4000K/5000K options, 120-277V input, 0-10V dimming, DLC Premium listing, and up to 4,066 lumens.

UL Listed
WARRANTY 5 YEARS
IP20
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The LEDone LOC-22TRKT from the LOC-##TRKT family is a versatile 2x2 LED troffer retrofit kit designed to modernize existing troffers with high-efficiency, selectable performance. Built for demanding commercial environments, it combines multi-watt and multi-CCT flexibility with long-life operation and low-glare illumination.

Key Features and Benefits

  • Field-selectable output with four wattage settings (15W/19W/24W/29W) for easier project standardization.
  • Selectable 3500K, 4000K, and 5000K CCT to match visual comfort and task needs.
  • DLC Premium listed and UL certified to support code-driven commercial upgrades.
  • 0-10V dimming standard for smooth control integration and energy savings.
  • Durable steel and aluminum construction with matte white finish for long-term reliability.
  • Backed by a 5-year limited warranty for added confidence in retrofit applications.

Specifications

  • Lumen Output: 2103.6|2664.56|3365.76|4066.2
  • Voltage: 120-277V
  • CRI: 83
  • Efficacy (lm/W): 140
  • Beam Angle: 110°
  • Power Factor: 0.9758
  • THD: 10.78
  • Rated Life (70 Hours): 100000
  • IP Rating: IP20
  • Max Ambient Temperature: 50°C
  • Form Factor: 2x2
  • Weight: 5.75lbs

Common Uses

Ideal for warehouses, schools, factories, offices, supermarkets, logistics centers, and exhibition halls where efficient, controllable, and low-glare troffer lighting is required.

RESOURCES AND DOWNLOADS

LEDone LOC-22TRKT LED Troffer Retrofit Kit Spec Sheet
