EiKO Global AAL1 Area Light, 150/130/100W, 3000/4000/5000K, Type V, 277-480V

By EiKO Global

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

EiKO Global AAL1 Area Light, 150/130/100W, 3000/4000/5000K, Type V, 277-480V

Now: $92.29
Reg: $269.05
Sale 66%
You save $ 176.76
  • SKU: E-AAL1-PS150-FCCTT5-V
  • MPN: AAL1-PS150-FCCTT5-V

Quick Overview

Illuminate parking lots, roadways, campuses, and other outdoor spaces with this 150/130/100W selectable EiKO AAL1 area light, featuring selectable 3000K-5000K CCT, Type V optics, and IP65 protection.

UL Listed
WET RATED
DAMP RATED
WARRANTY 5 YEARS
IP65
IK08
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The EiKO Global AAL1 Area Light delivers configurable, efficient outdoor illumination in the manufacturer’s versatile area-light series. This 150/130/100W model combines field-selectable color temperatures with Type V optics to adapt lighting to a range of site needs.

Key Features and Benefits

  • PowerSet output options of 150W, 130W, or 100W and FieldCCeT settings of 3000K, 4000K, or 5000K provide on-site flexibility; fixtures ship at the highest wattage and 5000K setting.
  • Controls-ready screw-in receptacle supports compatible standalone sensors and networked lighting controls without additional wiring.
  • Impact- and UV-resistant polycarbonate lens and IP65-rated construction help the fixture withstand outdoor conditions.
  • Hinged, toolless junction-box access simplifies installation and maintenance; a 3.3' (1 m) power cord is included.
  • UL Listed for the US and Canada, RoHS and FCC compliant, and DLC Premium qualified; backed by a 5-year limited warranty.
  • Mounts are available separately for a range of installation configurations.

Specifications

  • Wattage: 150W/130W/100W
  • Lumen Output: 21000/18200/14000
  • Color Temperature: 3000K/4000K/5000K
  • Efficacy: 140 lm/W
  • CRI: >80
  • Distribution: Type V (T5)
  • Input Voltage: 277-480V
  • Dimming: 0-10V, dim-to-off
  • Auxiliary Output: 12VDC, 100mA maximum
  • Power Factor: >0.9
  • THD: <20%
  • Estimated L70 Life: 100,000 hours
  • Operating Ambient Temperature: -40°F to 122°F (-40°C to 50°C)
  • Surge Protection: 10kV standard; 20kV optional
  • Housing: Bronze powder-coated die-cast aluminum
  • Lens: Impact- and UV-resistant polycarbonate
  • Ingress Protection: IP65
  • Impact Rating: IK08
  • Power Cord: 3.3' (1 m), pre-installed
  • Wiring Access: One 1/2" side knockout

Common Uses

Suitable for parking areas, automotive dealerships, roadways, campuses, streetscapes, airports, building facades, signs, entryways, and general area security lighting.
