Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V

By Halco Lighting Technologies
Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V
Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V
Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V
Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V
Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V
Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

Halco Retrofit Commercial Downlight with Emergency Battery Ready, 10", Lumen Selectable, Color Selectable, Haze Reflector with White Flange, Dual Dimming, 120-277V

$111.00
  • SKU: HLT-CDLEM-10-LS-CS-HZWH-DDV
  • MPN: CDLEM-10-LS-CS-HZWH-DDV

Quick Overview

10" commercial retrofit LED downlight with emergency battery-ready design, selectable 2800/3500/4500 lumens, 2700K-5000K CCT, 120-277V input, 0-10V or TRIAC/ELV dimming, 90+ CRI, wet location and IC airtight rated.

ETL Listed
Energy Star
Title 24 Compliant
WET RATED
IC RATED
WARRANTY 5 YEARS
IP65
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Want to save or compare this item?

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The Halco CDLEM Retrofit Commercial Downlight is a versatile 10" solution designed to modernize existing commercial recessed lighting with minimal installation effort. As part of Halco’s CDL family, it combines field-selectable output and color tuning with emergency battery-ready capability for dependable everyday and code-driven lighting performance.

Key Features and Benefits

  • Field-selectable lumen packages and 5-CCT tuning simplify inventory and on-site configuration.
  • Dual-dimming driver supports both 0-10V and TRIAC/ELV controls for broad compatibility.
  • Emergency battery-ready platform supports integral quick-connect backup for life-safety applications.
  • Haze reflector with white flange delivers a clean architectural look for commercial interiors.
  • Certified for demanding projects with ETL Listed, FCC, RoHS, Energy Star, and Title 24 compliance.
  • Backed by a 5-year limited warranty for long-term confidence.

Specifications

  • Lumen Output: 2800|3500|4500
  • Wattage: 25W|31W|38W
  • Voltage: 120-277V
  • Color Temperature: 2700K|3000K|3500K|4000K|5000K
  • CRI: 90
  • Beam Angle: 80°±10°
  • Power Factor: 0.9
  • Frequency: 50|60
  • Rated Life (L70): 50000 hours
  • Operating Temperature: -4°F to 104°F (-20°C to 40°C)
  • Ingress Protection: IP65
  • Weight: 2.2 lbs

Common Uses

Ideal for office parks, commercial buildings, maintenance facilities, educational campuses, and big-box retail spaces where flexible light levels, selectable CCT, and wet-location-rated recessed performance are required.

RESOURCES AND DOWNLOADS

Halco Retrofit Commercial Downlight with Emergency Battery Ready Spec Sheet
