ILP RB5 Kinetic Light Bay, Large Round High Bay, 26000lm|30000lm|36000lm, 120-277V, 3500K|4000K|5000K Selectable, Clear Polycarbonate Lens, Universal Hook & Cord Mount w/ 3/4" IP Pendant Adapter

By Industrial Lighting Products

Note: Product images are for illustration purposes only. Do not rely on product image alone to make a purchase decision. Actual product may vary due to specific configurations. Always refer to spec sheets for details.

ILP RB5 Kinetic Light Bay, Large Round High Bay, 26000lm|30000lm|36000lm, 120-277V, 3500K|4000K|5000K Selectable, Clear Polycarbonate Lens, Universal Hook & Cord Mount w/ 3/4" IP Pendant Adapter

$506.15
  • SKU: ILP-RB5L-26L/30L/36L-U-CCTS-PCL-KLB
  • MPN: RB5L-26L/30L/36L-U-CCTS-PCL-KLB

Quick Overview

High-output LED round high bay for warehouses and industrial spaces, featuring selectable 3500K/4000K/5000K CCT, 26,000/30,000/36,000 lumen package, 120-277V input, 0-10V dimming, IP65 optics, and IK10 impact resistance.

DLC Standard
Title 24 Compliant
DAMP RATED
WARRANTY 5|10 YEARS
IP65
IK10
In Stock & Ready To Ship!
Current Stock:Only left:
Estimate shipping in cart
Call, chat, or email
for support
Ships via

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax
Description

The ILP RB5 Kinetic Light Bay is a performance-driven round high bay designed for demanding commercial and industrial environments. As part of ILP’s RB5 lineup, it combines selectable light levels and CCT flexibility with rugged construction to simplify specification across varied applications.

Key Features and Benefits

  • Selectable lumen package (26L/30L/36L) and field-selectable CCT for easier project standardization.
  • Durable die-cast aluminum body with IK10-rated polycarbonate lens for high-impact areas.
  • IP65 sealed optical chamber helps protect performance in dusty or damp environments.
  • 0-10V dimming compatibility supports energy savings and lighting control integration.
  • Tested to LM-79 and LM-80 standards, RoHS compliant, and Title 24 compliant for code-focused projects.
  • Backed by a 5-year standard warranty with optional 10-year coverage.

Specifications

  • Voltage: 120-277V, 50/60Hz
  • Color Temperature: 3500K/4000K/5000K selectable
  • CRI: 80 minimum
  • Dimming: 0-10V (10%-100%)
  • Power Factor: >0.90
  • THD: <20%
  • Rated Life: L70 >100,000 hours
  • Surge Protection: 6kV minimum
  • Lens: Clear polycarbonate (PCL)
  • Mounting: Universal hook and cord mount with 3/4" IP pendant adapter
  • Ambient Temperature: Up to 40b0C for RB5L-26L/30L/36L package

Common Uses

Ideal for warehouses, manufacturing plants, distribution centers, gymnasiums, fitness centers, grocery facilities, and educational spaces requiring high-output, reliable overhead illumination.

RESOURCES AND DOWNLOADS

ILP RB5 Kinetic Light Bay Spec Sheet
